Introduction
SRX828----High power subwoofer
The SRX828 is a reference subwoofer designed to extend the frequency response of large format systems. The SRX828 features two high excursion, 18’’ direct radiating transducers mounted in a bass-reflex tuned enclosure. The L-Vents reduce turbulence and port noise at high levels while also increasing LF efficiency. The SRX828 operates from 25 Hz. The excursion capability of the transducer, combined with L-Vents contributes to deliver a high SPL, with low distortion. The SRX828 can offer standard or cardioid directivity, by combining physical deployment and the suitable preset.
| Specification | |
| System Type | Self powered dual 18”, subwoofer system |
| Frequency Range (-10dB) | 29 Hz - 150 Hz |
| Frequency Response (-3 dB) | 35 Hz - 120 Hz |
| Maximum SPL (1m) | 141 dB |
| Amplifier Design | Class D |
| Power Rating | 2000 W Peak |
| Dimensions (H x W x D) | 681mm x 1205mm x 574mm (26.79in x 47.42in x 22.57in) |
| Net Weight (each) | 93kg |
| EQ: | 20 parametric EQ's, speaker delay, and 50 available slots for presets |
| Inputs | Neutrik ¼ - XLR input; Neutrik XLR Output |
| Enclosure : | 18 mm Duraflex coated plywood |
| Outputs | 2 x XLR |
| LF Driver | 2 x 18 in Differential Drive® |
| System Processing | DSP based, resident in Input Module |
