Amplifier
SUB800 GETSHOW 800W 4 OHM Subwoofer Amplifier Module Professional Speaker Plate Amplifier
- Brand Name: GETSHOW
- Certification； CE
- Type： Power Amplifiers
- Origin: Mainland China
- Product description:
| Specification | |
| Model : | SUB800 |
| Output @8Ω/1KHz : | 800W |
Output @8Ω/1KHz : | 1200W |
| Frequency Response: | 20Hz-20KHz ±1dB |
| THD(10% RMS,1KHz): | ＜0.5% |
| Slew rate(RMS,1KHz): | ＞20V/μs |
| Damping Factor(RMS,1KHz): | ＞200 |
| Dynamic Range: | ≥95dB |
| S/N ratio (A-weighted,RMS): | ≥95dB |
| Sensitivity(RMS,1KHz): | 1,28V rms |
| Voltage gain: | 42dB |
| Input impedance: | Balanced:20K,Unbalanced:10K |
| N/W: | 2.4Kg |
| Average power consumption(music program): | 480W |
| Output circuit design: | CLASS D |
| protection: | PressureIimit,overheating,Short Circuit,DC,Switch no shock |
| Dimensions: | 332*142*85mm |
| Power supply: | AC100V---220V/50Hz~60Hz(Optional) |
