Power Amplifier
C Serious Digital Power Amplifier is with most advanced technology, Class C Power Amplifier integrated with DSP processor to make the performace easiler to control. Each amplifier is built-in Dsp audio processor, you can connect the amplifier with your computer or laptop through the sofware offered. One machine combines two different functions, the best value for performance.
| Specification | |
| Model: | C4-1.3K |
| type: | professional DSP control Digital Power Amplifier |
| Rated Power(2 ohm): | 4X2496W |
| Rated Power(4 ohm): | 4X2080W |
| Rated Power(8 ohm): | 4X1300W |
| power (bridge 4 ohm)Rated: | 2X4056W |
| power (bridge 8 ohm)Rated: | 2X3380W |
| Frequency Response: | 5HZ-20KHZ(±1dB) |
| THD: | <0.1% |
| Rate of conversion: | 28V/us |
| Coefficent of damping: | >240(1KHZ,8ohm) |
| SNR: | 110dB |
| input sensitivity: | 23dB 26dB 29dB 32dB 35dB 38dB 41dB 44dB |
| Impedance of input: | AC180V-264(50HZ-60HZ) |
| Power Supply voltage: | (Balanced)20KHZ ohm (Unbalanced)10KHZ ohm |
| Size of product: | 483mmX365mmX88mm |
| Size of package: | 570mmX472mmX145mm |
| N.Weight/G.Weight: | 13kg/15kg |
